步距角精度Step Angle Accuracy

± 10% (full step, no load)

电阻精度Resistance Accuracy

± 10%

电感精度Inductance Accuracy

± 20%

温升Temperature Rise

80°C Max. (rated current, 2 phase on)

环境温度Ambient Temperature

- 10°C ~ +50°C

绝缘等级Insulation Class

B

介电强度Dielectric Strength

500 VAC for one minute

V

A

W

Kg-cm

Kg

mm

42BY48L15

4-2

12

0.24

50

0.45

6

0.1

15

42BY48L20

2-2

6.5

1.0

6.5

1.1

4

0.13

22
